alec_b Posted November 7, 2011 Report Share Posted November 7, 2011 Being it's an SE, my car doesn't have performance shift. I did, however, notice today in the sunlight that there's two "PERF SHIFT" indicators. One is on the cluster, top left. There's also one identical above the low washer indicator in the DIC. What gives? Quote Link to comment Share on other sites More sharing options...
Mater Posted November 7, 2011 Report Share Posted November 7, 2011 the one on the dash is not wired not even on the cars with perf shift. no idea why GM did this on the cars with HUD it also shows there as well as the DIC Quote Link to comment Share on other sites More sharing options...
Psych0matt Posted November 7, 2011 Report Share Posted November 7, 2011 it's there so that if when the car was built it had performance shift, they could throw in a lightbulb instead of making another cluster Quote Link to comment Share on other sites More sharing options...
Euro Posted November 7, 2011 Report Share Posted November 7, 2011 the one on the dash is not wired not even on the cars with perf shift. no idea why GM did this on the cars with HUD it also shows there as well as the DIC I've seen plenty performance shift equipped cars have it light up on the dash Quote Link to comment Share on other sites More sharing options...
ptcfast2 Posted November 7, 2011 Report Share Posted November 7, 2011 Interesting Fact: Most (if not all) W's had tables in the computer for performance shift values for the car. Since some didn't come with a switch to enable the values (although the logic is there) you just need to replace the regular values with the performance ones and call it a day. GM also has a urban shift table hidden in some of the operating systems as well - bit harder to get to though. Quote Link to comment Share on other sites More sharing options...
Mater Posted November 7, 2011 Report Share Posted November 7, 2011 I've seen plenty performance shift equipped cars have it light up on the dash well i know for a fact 99 and 2000 do nto have it light up on tha dash and the bulb is not burned out either becuase there was no bulb even put on in to see as i thought it was odd to have a cut out but have it not light. it just lights up the DIC and the HUD. maybe it works on 97s and 98s on clubGP there is a write up on how to wire it in though to make it functional i can nto be bothered to try and make the search work though:lol: Quote Link to comment Share on other sites More sharing options...
alec_b Posted November 23, 2011 Author Report Share Posted November 23, 2011 Just a quick update: I ended up having my DIC and instrument cluster out a few days ago to replace the base DIC with the digital GT/GTP DIC with trip computer. While I had it all apart, I took a close look at how things were labeled on the circuit boards of the two instruments. On the back of the base DIC, the "PERF SHIFT" indicator was indeed labeled as such on the printed circuit, and was tinted with orange for the illumination. On the back of the instrument cluster, the "PERF SHIFT" indicator was labeled as "spare" on the circuit board, and tinted with blue for illumination. I also noticed that the digital DIC has a "Performance Shift" readout, but obviously that doesn't apply to my car. It appears as though the performance shift indicator was never meant to be used in the cluster itself, as it's not labeled on the circuit board. Quote Link to comment Share on other sites More sharing options...
9lumina6 Posted November 23, 2011 Report Share Posted November 23, 2011 97-98 and some earlier 99 GTP's (my roommate's 99 GTP lights up perf shift on the cluster, not the DIC) had the Perf Shift light in the dash...and 2000 GTP's it was on the DIC. My 00 GTP has the space on the gauge cluster I can see in the sunlight that's not hooked up...since it has it in the DIC. Quote Link to comment Share on other sites More sharing options...
GP1138 Posted November 23, 2011 Report Share Posted November 23, 2011 My GTP has it in the DIC too. Quote Link to comment Share on other sites More sharing options...
9lumina6 Posted November 23, 2011 Report Share Posted November 23, 2011 My GTP has it in the DIC too. Really? I thought 97's were in the cluster.....I stand corrected then. Quote Link to comment Share on other sites More sharing options...
digitaloutsider Posted November 24, 2011 Report Share Posted November 24, 2011 Truthfully, it's a total crapshoot as to what cars got it on the DIC and which ones got it on the cluster. 1998 (not 1997) was the first year for the cluster performance shift light. I have seen more 98's than anything else have the PS light on the cluster. I've also seen plenty with it on the DIC. I don't know if there was any real rhyme or reason. Interesting Fact: Most (if not all) W's had tables in the computer for performance shift values for the car. Since some didn't come with a switch to enable the values (although the logic is there) you just need to replace the regular values with the performance ones and call it a day. GM also has a urban shift table hidden in some of the operating systems as well - bit harder to get to though. The PS tables are really just tow/haul tables and in the PCMs that I've looked at, if it didn't come with PS/TH, the tables just mirror the standard shift values. Quote Link to comment Share on other sites More sharing options...
tornado_735 Posted November 24, 2011 Report Share Posted November 24, 2011 GM also has a urban shift table hidden in some of the operating systems as well - bit harder to get to though. I'm extremely intrigued by this for some reason....what are the shift characteristics? Quote Link to comment Share on other sites More sharing options...
white4d96 Posted November 24, 2011 Report Share Posted November 24, 2011 Why two performance shift indicators? Because RACECAR! Quote Link to comment Share on other sites More sharing options...
digitaloutsider Posted November 24, 2011 Report Share Posted November 24, 2011 The "urban" shift tables are intended to be used when the transmission is manually held in 1st/2nd gear. Quote Link to comment Share on other sites More sharing options...
Shifter23 Posted November 24, 2011 Report Share Posted November 24, 2011 Gangsta shift lol! Quote Link to comment Share on other sites More sharing options...
