White93z34 Posted April 12, 2010 Report Share Posted April 12, 2010 Some backstory. Last year Sam (go4damo) bought a black 92' z34 5 speed from someone local with a bad timing belt, well more specifically the timing was all jacked up and the car would not run. I mentioned at the last dayton meet that I would give him a hand with it when he was ready to fix it. And Saturday was just the day for that... Not too shabby for having 175,xxx mi on it. supposedly the engine was rebuilt 50k ago according to the last owner. we brought some "friends along" for encouragement Lets get started... Intake gasket job while I'm here, why the hell not!? Intrestingly enough the idlers and belt are in great shape. No prictures but the tensioner pulley was looking pretty sorry and the actuator was completely shot which is why the timing got all messed up. Disassemble all done, time to reinstall this shizzle. Brand new parts make me happy Crank timing set Belt on, rotate crank 360* set front cams, lock down and done. I don't have any more pictures but after It got put together, the old girl fired right up and it runs awesome. Rather rewarding to hear it run for the first time ever. Aparently the PO did not believe in complete cam cover gaskets, all 6 O rings for the spark plug holes were missing which let a good bit of oil get in the plug holes. A few other asshole things were done, but nothing too bad. I am really suprised how decent it runs with the miles it has, it has new: Timing set Spark plugs (rapidfires) valve cover gaskets plug wires oil change Pretty productive weekend. and If I can i may do a timing belt write up from this. Quote Link to comment Share on other sites More sharing options...
slick Posted April 12, 2010 Report Share Posted April 12, 2010 I guess maybe I'm not familiar enough with the job, but how did you get the cam cogs off, and why did you pull them off? Quote Link to comment Share on other sites More sharing options...
White93z34 Posted April 12, 2010 Author Report Share Posted April 12, 2010 you use a special puller to get them off, its visible in a few of the pictures. you pull 3 of them all but the very back one (because you can't get the tool in there.the front rear one is pulled just to make getting the belt lined up easier, and the front ones have to be pulled so you can rotate the engine without the front cams moving. Quote Link to comment Share on other sites More sharing options...
WhatTheFehl Posted April 12, 2010 Report Share Posted April 12, 2010 Wow, looks like you had a fun weekend! I did some work on my car but nothing like this! Quote Link to comment Share on other sites More sharing options...
GOT2B GM Posted April 12, 2010 Report Share Posted April 12, 2010 Nice work Chris, and nice car Sam! Quote Link to comment Share on other sites More sharing options...
GOT2B GM Posted April 12, 2010 Report Share Posted April 12, 2010 Chris, is there always a posse of Luminas where ever you go? Quote Link to comment Share on other sites More sharing options...
GP1138 Posted April 12, 2010 Report Share Posted April 12, 2010 I love the constant Lumina posse!!! LOLOL I loved doing my timing belt job for some reason. We must have that gene that makes us immune to bitch engine jobs. Quote Link to comment Share on other sites More sharing options...
Z34guy Posted April 12, 2010 Report Share Posted April 12, 2010 Ah.... another old W returned to the road Quote Link to comment Share on other sites More sharing options...
IRONDOG442 Posted April 12, 2010 Report Share Posted April 12, 2010 Hey Is this a 75 Caddy or a Olds 98 Its a two door so either way its a rare bird! Quote Link to comment Share on other sites More sharing options...
White93z34 Posted April 12, 2010 Author Report Share Posted April 12, 2010 I can think of much worse jobs to do then this TBH, however no mater how you cut it the job is time consuming as all hell even if you know exactly what you are doing. Quote Link to comment Share on other sites More sharing options...
AL Posted April 13, 2010 Report Share Posted April 13, 2010 Awesome work guys... I almost forgot about that car... Hope to see more progress on it soon! Quote Link to comment Share on other sites More sharing options...
jeremy Posted April 13, 2010 Report Share Posted April 13, 2010 nice work Chris......you are definitely a very good man when it comes to sharing knowledge and wrench time.... Quote Link to comment Share on other sites More sharing options...
96oldsmobubble Posted April 13, 2010 Report Share Posted April 13, 2010 Damn you guys! You make me want to enter into the DOHC world! Thanks for the great info, I always like to learn more tips Quote Link to comment Share on other sites More sharing options...
